Geonex HZR610 Horizontal Drilling Rig

The Geonex HZR610 is a powerful and adaptable horizontal boring rig for large-diameter casing installations. Supporting diameters from Ø219.1 mm to Ø812.8 mm, it’s built to deliver high torque and reliable accuracy in longer crossings and heavier ground conditions. Whether you’re boring beneath highways, railways, rivers, or industrial zones, the HZR610 combines force, control, and versatility in one robust system.

Key Specifications

  • Suitable for steel casing installations from Ø219–813 mm in infrastructure, energy, and utility sectors.
  • Maintains performance in rock, blasted fill, and mixed soil—no tool changes required mid-bore.
  • Modular frame and extension options enable up to 400 m bore lengths in solid rock.
  • Delivered with integrated power pack, compressor, and radio control.
Contact us
150 m
Or 450ft Drilling Length in mixed soil
813 mm
Or 32” in Max Drilling diameter
55,000 Nm
of Torque
8,1 m
Or 26’7” in Length of rig

The Benefits of the HZR400

Large Diameter Capability with Control

HZR610 fills the gap between mid-size and mega-capacity rigs. With support for casing sizes up to Ø812.8 mm, it allows contractors to take on more complex installations without the need for oversized machines. The rig is equipped with high feed force, multiple rotation gears, and remote-controlled hydraulic alignment for precise entry—even on uneven surfaces.

Designed for Long Bores and Difficult Soils

From urban utility corridors to mountain crossings, the HZR610 delivers dependable results in variable ground. It performs consistently through boulders, backfill, fractured rock, and transitions—keeping productivity high without sacrificing control. It’s especially suitable for pit-to-pit crossings where length and alignment must be maintained.

Power Pack Options for HZR610

The HZR610 is powered by the Geonex PP205 power pack, a high-output diesel-driven unit with integrated air system and remote control functionality. With multiple hydraulic circuits and rugged construction, the PP205 supports the rig’s torque and feed requirements even in continuous heavy-duty use. Optional frame extensions and auxiliary modules expand its application range further.

Wide range of drilling equipment

Geonex offers a full suite of tooling for the HZR610, including DTH hammers, pilot bits, ring bits, augers, and hole openers—covering casing sizes from Ø219 mm to Ø812 mm. The modular tool system allows fast adaptation between bores, reducing idle time and making the HZR610 a highly flexible platform for changing project needs.

Order Geonex brochure

Learn more about Geonex products and how they fit the requirements of your trechless projects.
Order Geonex brochure
Privacy Policy
Privacy Policy

1. Introduction

In accordance with the EU regulations Geonex Oy (hereinafter referred to as “Geonex” and/or “we” and/or “us”) is responsible for the processing of your personal data. Looking after the personal data you share with us is a responsibility we don’t take lightly. We want you to be confident that your data is secure with us, and understand how we use it to offer you a better customer experience.

2. Data controller

Geonex Oy (Business ID: 2134727-3)

3. Contact details for matters related to the register

Email address: kimmo.juvani@geonex.fi

Street address: Teollisuustie 9, 95600 Ylitornio, Finland

4. The name of the register

Customer, partnership and marketing register.

5. The purpose and legal basis for the processing of personal data

We only process your personal data if this is permitted by an applicable legal regulation. The processing of your data is based on a contractual relationship between a customer/partner and Geonex, or a separate consent for the processing of customer information. The goal for the register is to make services available to you, manage and improve our day-to-day operations, personalise your Geonex experience as well as contact and interact with you.

6. Utilisation of cookies and similar techniques

A cookie is a file containing an identifier (a string of letters and numbers) that is sent by a web server to a web browser and is stored by the browser. The identifier is then sent back to the server each time the browser requests a page from the server. Cookies do not typically contain any information that personally identifies a user, but personal information that we store about you may be linked to the information stored in and obtained from cookies. We use cookies and similar technologies on our website to improve your customer experience. Users may, of course, choose not to accept cookies from our website.

7. Content of the register

The register may include, but is not limited to the following information:
Usage data [data about your use of our website and services]
Account data [may include your name and email address]
Profile data [your information included in your personal profile on our website]
Service data [your personal data that are provided in the course of the use of our services]
Publication data [information that you post for publication on our website or through our services]
Enquiry data [information contained in any enquiry you submit to us regarding goods and/or services]
Customer relationship data [information relating to our customer relationships, including customer contact information]
Transaction data [information relating to transactions, including purchases of goods and services, that you enter into with us and/or through our website]
Notification data [information that you provide to us for the purpose of subscribing to our email notifications and/or newsletters]
Correspondence data [information contained in or relating to any communication that you send to us]

8. Sources of information for the register

We collect information from you when you submit it to us, for example, when you request services or information from us. Registers are purchased for marketing purposes.

9. Disclosure information

Your personal data may be disclosed within the organisation of the data controller and its subsidiaries and sister companies and to our collaboration partners for the realisation of the purposes described herein. Otherwise, data is only disclosed to the extent permitted or required by law.

We may need to transfer your personal data outside of the European Economic Area (EEA) if it is necessary for the realisation of the service. In such cases, we will make sure that any transfer of your personal data is subject to appropriate protections as if it were being processed inside the EEA.

10. Data subject’s rights related to data processing

We know how important it is to protect and manage your personal data. You have the right to see the personal data we hold about you. Also, the data controller only collects and processes information that is necessary for its operations. Personal data that we process for any purpose or purposes shall not be kept for longer than is necessary for that purpose or those purposes.

  • Your principal rights under data protection law are:
  • the right to access;
  • the right to rectification;
  • the right to erasure;
  • the right to restrict processing;
  • the right to object to processing;
  • the right to data portability;
  • the right to complain to a supervisory authority; and
  • the right to withdraw consent.

11. Third-party websites and services

We are not responsible for the practices employed by websites, applications, or services linked to or from our site, including the information or content contained there. We recommend users check the privacy policies of any other websites they use.

12. Amendments

We may update this policy from time to time by publishing a new version on our website. You should check this page occasionally to ensure you are happy with any changes to this policy.

Geonex HZR610 Technical Specifications

Category
EU
USA
Casing Diameter
219,1 mm – 812,8 mm
8 5/8” – 32”
Radio Controlled
Yes
Yes
Feed force 1 gear, slow
400 KN / 300 bar
89,900 lbf / 4,350 psi
Feed force 2 gear, fast
200 KN / 300 bar
44,960 lbf / 4,350 psi
Feed speed 1 gear, slow
10 m/min
32 ft/min
Feed speed 2 gear, fast
20 m/min
64 ft/min
Torque (1st Gear)
55 000 Nm / 300 bar
40,565 ft-lb / 4,350 psi
Torque (2nd gear)
39 000 Nm / 300 bar
28,760 ft-lb / 4,350 psi
Speed (1st gear)
13 rpm
13 rpm
Speed (2nd gear)
19 rpm
19 rpm
Weight ( with Shortening frame section)
7 450 kg
16,430 lb
Weight ( without Shortening frame section)
6690 kg
14,750 lb
Weight ( without Shortening frame section)
5 700 kg
12,570 lb
Length
5 100 mm + 3 000 mm
16’9” + 9’11”
Width
2 360 mm
7’9”
Height (jack legs)
2 200 mm
7’3”
Options
Shortening frame section
3 000 mm
9’11”
Shortening frame section
760 kg
1,680 lb
Extension frame
5 900 mm
19’5”
Extension frame
1 950 kg
4,300 lb
